Cube Portable Toilet

Product line for Europe

The Cube portable toilet is the workhorse among the Armal products. It is a real step ahead in the portable sanitation industry and is the result of years of manufacturing experience. Cube offers the maximum ease of use for its operators and a design that shows Armal’s eye for details and for the needs of those in the portable toilet rental business.

Armal uses the most resistant materials which have been transformed using highly-precise methods, combined with an engineering project. The main objectives for the Armal toilets are ease of use and safety. Cube portable toilet comes with the wall urinal, the coat/tool-belt hook and 3-rolls toilet paper holder.

CUBE Portable Toilet, specially conceived for construction sites and important events of big public affluence, has a practical and elegant design at the same time.

CUBE portable toilet is very versatile and can be configured with several optional fittings.

Technical specifications

  • Weight empty76 Kg
  • Tank capacity210 l approx.
  • Seat Height51 cm
  • Internal dimensions (L/D/H)100 x 100 x 212 cm
  • External dimensions (L/D/H)106 x 106 x 233 cm
  • Material used High density grade 4 polyethilene. Anti UV Treatment
  • Number of uses230

Some overseas loading simulations (standard unit without accessories):

  • 20 ft. container: 20 unassembled units
  • 40 ft. container: 44 unassembled units
  • 40 ft. High Cube container: 88 unassembled units

Some inland loading simulations (standard unit without accessories):

  • 1 pallet (4 unassembled units) 105x105x245 cm
  • 6,5 mt. Truck: 48 unassembled units (12 pallets)
  • 13,6 mt. Truck: 96 unassembled units (24 pallets)

Standard Fresh Water Flush (Hand or Foot Pump) + Standard Hand Wash Sink (Hand or Foot Pump)

View details

Fresh Water Flush Waterwall + Standard Hand Wash Sink with Hand Pump

View details

Fresh Water Flush Waterwall + Standard Hand Wash Sink with Foot Pump

View details

Fresh Water Flush Waterwall + Hand Wash Sink Waterwall

View details

Recirculating System (Hand or Foot Pump) + Standard Hand Wash Sink (Hand or Foot Pump)

View details

Recirculating System (Hand or Foot Pump) + Hand Wash Sink Waterwall

View details

*many other combinations available.

Hand Wash Sink with Hand Pump

View details

Hand Wash Sink with Foot Pump

View details

Hand Wash Sink Waterwall

View details

Hand Wash Sink Junior

View details

Fresh Water Flush System with Hand Pump

View details

Fresh Water Flush System with Foot Pump

View details

Fresh Water Flush Waterwall

View details

Re-circulating Flushing System with Hand Pump

View details

Re-circulating Flushing System with Foot Pump

View details

Calculate the required number of portable toilets and demand a quote!

According to the European Regulations EN 16194

Calculate now!
